Description
Engineered for portability without sacrificing performance, the PingLive Mini Sonar delivers real-time underwater imaging in a compact, lightweight form factor. Whether you're casting from a kayak, a compact boat, or setting up on the ice, this high-performance sonar fits seamlessly into tight spaces—yet still packs the punch of much larger systems.
Live Imaging: Combo View+ Forward View+ Down View
Enjoy Industry's first Combo View, which lets you see Forward View and Down View simultaneously— giving you much larger live image of what’s ahead and beneath your boat at the same time.
Down View designed to see the activity beneath your boat with a 39-degree view or directly beneath an ice hole
Forward View to cover various fishing scenarios
Down View (Scan) + Traditional View (2D Chirp)
Down View (scan) produces a photographic-like image of structures, vegetation, and fish directly beneath the boat.
Traditional View Produces a colored 2D display showing arches for fish and bottom hardness.
Portability: At just 1.5 inches thick and 1.4 pounds, it’s designed for anglers fish all year round.
Simple Power & Connectivity: Operates on 11–18 VDC and supports both wired and optional wireless connections via the Accuphy WiFi Router.
iOS & Android: Control and view live sonar data with Accuphy Sonar app on compatible iOS and Android devices.
Whether you're drop-shotting from a boat/ kayak or jigging through the ice, the PingLive Mini gives you the live sonar edge—compact, clear, and crafted for serious anglers.
Compatible Devices
Find the complete list of Apple and Android devices that are compatible with PingLive below, so you can confirm your device works seamlessly.
Transducer Beamwidth: 39° (Live forward & Live down)
Transducer Cable Length: 6m, or 20ft
Transducer Number of PINs: 8
Temperature Range: 0°c to 40°c, or 32°f to 104°f
Router One Specifications
Dimensions: 3.35 x 2.95 x 1.38 in Weight: 0.12 kg Temperature Range: -20°C to 40°C Transducer Ports: 1 Power Input: 11-18 VDC Power Usage: 3W typical, 6W max Frequency: 2.4/5.8GHz Wi-Fi Modes: IEEE802.11A/B/G/N/AC Wi-Fi Effective Range: 70 ft*
*A power source capable of supplying at least 6A output is required.
Obține vizibilitate completă sub apă cu imagistică sonar simultană în jos și în față, oferită printr-un fascicul larg de 78° pentru claritate de neegalat.
Vizualizare În Jos
Ideală pentru identificarea peștilor sub barcă și pentru jigging vertical de precizie.
Vizualizare Frontală
Scanează în față în timp real. Detectează peștii și structurile.
Vizualizare Tradițională
Detaliile multi-frecvență evidențiază separarea țintelor cu claritate. Perfectă pentru urmărirea nălucilor și a bancurilor de pești.
Scanare În Jos
Scanarea de înaltă rezoluție afișează structurile cu detalii aproape fotografice.
VIEWING OPTIONS
Combo View
Forward + Down (Simultaneously)
Unlock full underwater awareness with simultaneous downward and forward sonar imaging, delivered through a wide 78° beam for unmatched clarity.
Down View
Ideal for identifying fish below the boat and precision vertical jigging.
Forward View
Scan ahead in real time. Detect fish and structure.
Traditional View
Multi-frequency detail reveals target separation with clarity. Perfect for tracking bait and fish schools.
Down Scan
High-resolution scanning shows structures with photographic detail.
ROUTER ONE
CONEXIUNE WI-FI.
Fără latență · Conexiune 5G · Rază de 70 ft · Imagistică live + mobilitate
ROUTER ONE
WI-FI CONNECTION.
No Latency · 5G Connection · 70ft Range · Live Imaging + Mobility
